Manual Hydraulic Mini Stacker 200kg – Foldable Hand Forklift
Colombo · JTC
Rs. 121,500
In stock at last catalogue checkCategoryHandling & Access
SellerJTC
Product SKU53001577
Information checked26 Oct 2026
Ask about the exact model, current stock, price and delivery. Arrange your purchase directly with the seller.
Check the goods and agree on payment and delivery with the seller. TradePola does not collect payments.
About this product
A manual hydraulic stacker for compact lifting tasks
This mini hand forklift uses a hydraulic foot pump and chain-supported carriage to raise goods on two adjustable forks. Its 200 kg rated capacity and 900 mm maximum fork height suit compact lifting and positioning tasks in workshops, storerooms and small warehouses.
The forks and support legs fold for storage and transport. Two large solid rear wheels and front swivel castors support manual movement on suitable firm, level surfaces. The lifting system does not need electricity.
Specifications
Rated load capacity ·
200 kg ·
Fork lifting range ·
80–900 mm ·
Fork length × width ·
540 × 70 mm per fork ·
Inner fork width ·
360 mm, as listed in the manual ·
Outer fork width ·
500 mm, as listed in the manual ·
Body length × width × height ·
900 × 750 × 1,210 mm ·
Front wheel diameter ·
50 mm ·
Rear wheel diameter ·
250 mm ·
Base leg length × width ·
630 × 540 mm ·
Inner / outer base leg width ·
420 / 480 mm ·
Net weight ·
45 kg ·
Lift operation ·
Manual hydraulic foot pedal with release control ·
Storage configuration ·
Foldable support legs and forks; adjustable fork position ·
Colour ·
Yellow frame with black forks and hydraulic assembly ·
Dimensions and rated values are taken from the supplied product manual. Check the fork position, support-leg clearance and load footprint for your application.
Check your goods and pallet clearance
Match the complete load weight to the 200 kg rating and the required working height to the 80–900 mm fork range. Check that the goods sit securely on the 540 mm forks.
For a pallet, check its entry height, openings and underside arrangement against the forks and support legs. Pallet compatibility depends on those clearances; it is not established by the weight rating alone. Contact JTC if you need a fit check.
Operation and storage
Follow the supplied operating and assembly instructions. Keep the load evenly supported within the fork length, observe the rated capacity, and keep people clear of moving parts. This equipment is for goods handling and must not lift people.
Fold the unloaded forks and support legs only according to the supplied instructions. Folded overall dimensions are not listed in the manual.
Ordering and delivery
Choose your quantity using the buying controls above. Contact JTC with your delivery destination and load requirements to confirm delivery or collection arrangements.
Frequently asked questions
How much can this mini stacker lift?
The supplied product manual lists a maximum load of 200 kg. Match the complete load weight and load support to that rating.
What is its lifting height?
The forks lower to 80 mm and rise to a maximum of 900 mm, according to the supplied manual.
Is it a manual forklift or a pallet jack?
This is a manual hydraulic stacker, also commonly called a mini hand forklift. It raises its fork carriage for positioning goods. A conventional pallet jack mainly lifts a pallet just clear of the floor for movement.
Does it fold for storage?
The supplied manual identifies it as a foldable mini stacker and shows folding support legs and forks. It does not list folded overall dimensions.
Can it handle my pallet?
Check pallet entry height, opening width and underside clearance against the forks and base legs. Provide your pallet measurements to JTC before choosing it for that task.
Does it need electricity?
No. The lifting mechanism uses a manually operated hydraulic foot pedal and release control.
Explore material handling
View hydraulic stackers and scissor lift tables or browse all trolleys.
